Reattori
Behälter KG offers high quality stainless steel reactor vessels in various sizes. Sorted by volume in ascending order, you find below a wide range of second hand reactor vessels that have previously been used in the pharmaceutical and chemical industries. All items are immediately available from stock and can be shipped worldwide.
- 946759 liter heat-/coolable Becomix system, Aisi 316 with control 19.000,00 €
- Riscaldabile: 4,0 bar
- Pressione massima:2,0 bar
- Coibentazione
- Elemento miscelante :Agitatore ad ancora
- Motore:18 - 108 rpm
- Potenza:0.55 KW
- documenti disponibili:
- 8639120 liter heat-/coolable pressure tank, Aisi 316 3.900,00 €
- Riscaldabile: 1,0 bar
- Pressione massima:1,5 bar
- Elemento miscelante :Agitatore magnetico
- Altezza Totale: 1.350 mm
- Altezza Cilindrico/mm: 750 mm
- Diametro interno: 400 mm
- Diametro esterno: 500 mm
-
- Riscaldabile: 4,0 bar
- Pressione massima:1,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore ad elica marina
- Motore:156 - 838 rpm
- Potenza:0.75 KW
- ceritficato EX:
- Altezza Totale: 2.400 mm
- Diametro interno: 590 mm
- Diametro esterno: 800 mm
-
- Riscaldabile: 3,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore ad elica marina
- Motore:71 - 640 rpm
- Potenza:0.34 KW
- ceritficato EX:
- Altezza Totale: 2.000 mm
- Altezza Cilindrico/mm: 470 mm
- Diametro interno: 690 mm
- Diametro esterno: 830 mm
- 7899265 liter heat-/coolable pressure tank, Aisi 304 3.950,00 €
- Riscaldabile: 0,5 bar
- Pressione massima:20,5 bar
- Elemento miscelante :Agitatore ad elica marina
- Motore:90 - 546 rpm
- Potenza:1.5 KW
- ceritficato EX:
- Altezza Totale: 3.350 mm
- 8140280 liter heat-/coolable pressure tank, Aisi 316 10.500,00 €
- Riscaldabile: 3,0 bar
- Pressione massima:3,5 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Motore:339 rpm
- Potenza:0.55 KW
- documenti disponibili:
- Altezza Totale: 2.100 mm
- Altezza Cilindrico/mm: 630 mm
- Diametro interno: 740 mm
- Diametro esterno: 900 mm
- S12453280 Liter temperierbarer Druckbehälter aus V2A 4.195,00 €
- Riscaldabile
- Pressione massima:2,5 bar
- Coibentazione
- Elemento miscelante :Agitatore a disco
- Altezza Cilindrico/mm: 1.000 mm
- Diametro interno: 600 mm
- Diametro esterno: 780 mm
- 8617313 liter heat-/coolable pressure tank, Aisi 316 4.950,00 €
- Riscaldabile: 3,0 bar
- Pressione massima:3,0 bar
- Coibentazione
- Elemento miscelante :Flangia
- Altezza Totale: 1.600 mm
- Altezza Cilindrico/mm: 830 mm
- Diametro interno: 620 mm
- Diametro esterno: 730 mm
- 6873313 Liter heiz-/kühlbarer Druckbehälter aus V4A 2.900,00 €
- Riscaldabile: 10,0 bar
- Pressione massima:3,0 bar
- Elemento miscelante :Agitatore ad ancora
- Altezza Totale: 3.050 mm
- Altezza Cilindrico/mm: 630 mm
- Diametro interno: 700 mm
-
- Riscaldabile: 6,0 bar
- Pressione massima:4,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Potenza:0.37 KW
- documenti disponibili:
- Altezza Totale: 2.050 mm
- Altezza Cilindrico/mm: 990 mm
- Diametro interno: 650 mm
- Diametro esterno: 810 mm
-
- Riscaldabile: 4,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Motore:377 rpm
- Potenza:0.55 KW
- Altezza Totale: 1.830 mm
- Diametro interno: 770 mm
- Diametro esterno: 910 mm
- 9449435 liter heat-/coolable pressure tank, Aisi 316 7.500,00 €
- Riscaldabile: 2,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Flangia
- Altezza Totale: 1.650 mm
- Altezza Cilindrico/mm: 670 mm
- Diametro interno: 770 mm
- Diametro esterno: 940 mm
- 15886Ungebrauchter 500 Liter heiz-/kühlbarer Druckbehälter aus V4A (1.4539) mit Magnetrührer 28.000,00 €
- Riscaldabile: 10,0 bar
- Pressione massima:6,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Motore:408 rpm
- Potenza:0.37 KW
- documenti disponibili:
- Altezza Cilindrico/mm: 1.015 mm
- Diametro interno: 780 mm
- Diametro esterno: 960 mm
-
- Riscaldabile: 3,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore ad elica marina
- Motore:670 rpm
- Potenza:0.55 KW
- documenti disponibili:
- Altezza Totale: 2.250 mm
- Altezza Cilindrico/mm: 900 mm
- Diametro interno: 800 mm
- Diametro esterno: 900 mm
-
- Riscaldabile: 2,0 bar
- Pressione massima:3,0 bar
- Coibentazione
- Elemento miscelante :Agitatore a pala
- Altezza Totale: 2.300 mm
- Diametro interno: 650 mm
- Diametro esterno: 890 mm
- 7029630 Liter heiz-/kühlbarer Druckbehälter aus V4A 3.900,00 €
- Riscaldabile: 32,0 bar
- Pressione massima:6,0 bar
- Vuoto massimo:1,0 bar
- Elemento miscelante :Agitatore ad ancora
- Altezza Totale: 2.000 mm
- Altezza Cilindrico/mm: 800 mm
- Diametro interno: 1.000 mm
- 7799650 Liter heiz-/kühlbarer Druckbehälter aus V2A 6.500,00 €
- Riscaldabile: 8,0 bar
- Pressione massima:1,5 bar
- Coibentazione
- Elemento miscelante :Agitatore ad elica marina
- Motore:1.415 rpm
- ceritficato EX:
- documenti disponibili:
- Altezza Totale: 2.380 mm
- Altezza Cilindrico/mm: 900 mm
- Diametro interno: 900 mm
- Diametro esterno: 1.040 mm
-
- Riscaldabile: 3,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore a pala
- documenti disponibili:
- Altezza Totale: 3.250 mm
- Altezza Cilindrico/mm: 1.000 mm
- Diametro interno: 820 mm
- Diametro esterno: 955 mm
-
- Riscaldabile: 3,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore ad elica marina
- Motore:255 / 510 rpm
- Potenza:1.1 / 1.4 KW
- documenti disponibili:
- Altezza Totale: 3.250 mm
- Altezza Cilindrico/mm: 1.000 mm
- Diametro interno: 820 mm
- Diametro esterno: 955 mm
- 7464720 Liter heiz/-kühlbarer Druckbehälter aus V4A 3.900,00 €
- Riscaldabile: 6,0 bar
- Pressione massima:2,0 bar
- Elemento miscelante :Agitatore a pala
- Altezza Totale: 2.250 mm
- Altezza Cilindrico/mm: 1.220 mm
- Diametro interno: 790 mm
-
- Riscaldabile: 6,0 bar
- Pressione massima:4,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Motore:329 rpm
- Potenza:0.55 KW
- documenti disponibili:
- Altezza Totale: 2.300 mm
- Altezza Cilindrico/mm: 1.150 mm
- Diametro interno: 900 mm
- Diametro esterno: 1.060 mm
-
- Riscaldabile: 6,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Motore:416 rpm
- Potenza:0.55 KW
- documenti disponibili:
- Altezza Cilindrico/mm: 864 mm
- Diametro interno: 1.000 mm
-
- Riscaldabile: 6,0 bar
- Pressione massima:3,0 bar
- Vuoto massimo:1,0 bar
- Coibentazione
- Elemento miscelante :Agitatore magnetico
- Motore:412 rpm
- Potenza:0.75 KW
- documenti disponibili:
- Altezza Totale: 2.100 mm
- Altezza Cilindrico/mm: 906 mm
- Diametro interno: 988 mm
- Diametro esterno: 1.270 mm
-
- Riscaldabile: 3,0 bar
- Pressione massima:4,0 bar
- Coibentazione
- Elemento miscelante :Agitatore ad elica marina
- Potenza:5.5 KW
- documenti disponibili:
- Altezza Totale: 2.950 mm
- Altezza Cilindrico/mm: 1.200 mm
- Diametro interno: 1.000 mm
- Diametro esterno: 1.210 mm
Definition of a reactor vessel
A reactor is a stainless-steel vessel that is specially designed to carry out chemical reactions, hence the transformation of one set of chemical substances to another. Reactors have the following special design features:
- Double jacket for heating / cooling: this allows to control the process heat inside the reactor
- Working pressure: depending on the reaction, overpressure or underpressure can arise inside the vessel
- Agitation: a reaction often arises by combining different raw materials, which then need to be homogenized through an appropriate agitator
Which reactor vessel types exist?
The design characteristics of a reactor are primarily determined by the basic parameters of the substances to be processed inside. The following reactor types can be distinguished:
- Chemical reactor: i.e. designed for the processing of polymers - such reaction vessels have a powerful stirrer for high viscosity applications, massive wall thicknesses, dished bottoms, half-coil pipes around the cylindrical part and lower bottom and are installed either on support brackets or on four solid legs
- Pharmaceutical reactor: i.e. for the processing of sterile active ingredients – depending on the size the reactor is mounted on wheels or positioned on legs and needs to fulfil the highest qualitative standards in terms of manufacturing quality, surface roughness and technical documentation
- Bioreactor / fermenter: primarily designed to cultivate organisms or cells in the biotechnological or in the pharmaceutical industries, therefore, with the highest demands on sterility and purity
Due to the often-involved high temperature levels and demanding process handling, stainless steel reactors are often manufactured in highly resistant stainless-steel grades, such as AISI 316, AISI 316L or AISI 316 Ti.
Those parts not in contact with the product (i.e. legs, dimple jacket, insulation jacket) are often manufactured in AISI 304. For particularly critical applications, enameled reactors (glass-coated), titanium reactors or hastelloy reactors remain to be a option of choice.
Which mixing technology can be used in a reactor vessel?
Basic stirring tasks of a reactor vessel can include homogenizing, suspending, dispersing, emulsifying and gassing, depending on the viscosity of the product before and after the reaction. The following stirring elements and impellers are particularly suitable for the respective stirring tasks:
- propeller stirrer: well suited for simple homogenization of aqueous substances such as solvents, as a directly driven high-speed mixer or with lower speed though a geared motor for more gentle mixing (e.g. milk or dairy products)
- anchor agitator / frame stirrer: slow-speed, anchor-shaped agitator for highly viscous substances, i.e. adhesives, resins or silicones
- blade stirrer: slow-speed geared agitator with blade-shaped agitator elements, for a gentle homogenization of low- to medium-viscous products, such as paints, coatings or shampoo
- pitched-blade impeller: 4-blade impeller element, installed at a 45° angle, suitable for homogenizing, dispersing, suspending and degassing with a comparatively high-power input
- dissolver: support plate with tooth-like circumferencing elements, the dissolver generates high shear forces and is suitable for dispersion, emulsification or wet milling (e.g. printing inks, pigment pastes or plasters)
- cup stirrer: slow-speed cone shaped cups, particularly suitable for the gentle homogenization and degassing of aqueous to viscous substances, without shear forces (e.g. soap, oils, lotions, shampoo)
- jetstream-mixer: fast-running rotor-stator agitator, for very fast homogenization without air entry and sedimentation
- Magnetic stirrer: installed in the bottom of the tank, designed for aseptic mixing applications and very small amounts of product to be mixed (e.g. eye drops, active ingredients, laboratory tests)
Benefits of second-hand reactor vessels
Used reactors are immediately available from our stock and can be shipped worldwide. Due to our large stock of high-quality used stainless-steel reactor vessels from the chemical and pharmaceutical industries, we can offer a suitable reactor option for almost any field of application. Custom-made new reactors, in contrast, often come with a lead time of about 12 months due to the large manual workload and various sub suppliers that are involved.
Also, the required investment in a second-hand reactor tank is significantly less than an equivalent new reactor vessel. This is especially the case when particularly high temperatures (i.e. up to 300°C), pressure levels above 6.0 bar or complex agitator technology are required, such as a coaxial agitator or a wall-scraping anchor stirrers. Used reactors are often already equipped with measurement and control technology or have load cells mounted below the legs. These otherwise very expensive accessories are often included in a second-hand reactor without additional cost.
Since our used reactors are almost exclusively sourced from German-speaking countries, they mostly come from well-known manufacturers such as Hagemann, Diessel, Seitz or Waldner. This ensures a long operational life expectancy based on superb material processing and manufacturing quality.
Brand new custom-made reactor vessels
With over 50 years of experience in vessel and tank construction, Behälter KG is at your side as knowledgeable partner for made-to-measure stainless steel reactors. We would be happy to provide you with an individual offer for your reactor needs, please contact us by phone or via our
.
Our manufacturing capabilities range from smaller pharma-grade reactor tanks up to larger chemical reactor vessels, with made-to-measure mixing technology (if required also ATEX). We are looking forward to hearing from you!
