Brand new 3300 liter heat-/coolable tank, AISI 304 (type FIT; optional with agitator)

€8,290.00
price per piece
3 pieces on stock
Dokumentation
General Information
location
Bremen
condition
brand new
Vessel
volume
3.331 liter
max. allowable working temperature
90 °C
specific weight of the medium
1.3 (to/m³)
construction
standing
stand type
legs height adjustable
quantity legs
4 Piece
double jacket
double jacket
available
Volume double jacket
32,0 liter
max. allowable working overpressure (dj)
2.0 bar
max. allowable working temperature (dj)
120 °C
Temperature control cylinder (dj)
thermo plate
temperature control bottom (dj)
thermoplate
Technical Characteristics
diameter inside
1.592 mm
cylindrical height
1.500 mm
total height
2.600 mm
Wall thickness lower bottom
3.0 mm
wall thickness cylinder
3.0 mm
wall thickness of upper bottom
2.5 mm
Equipment
Technical documentation
drawing
manhole
in the upper bottom
nameplate
technical equipment
ventilation, crane eyes
outlet
DN50 DIN 11851
Material Composition
surface outside
high-gloss
surface inside
high-gloss
Material in contact with medium
AISI304 (V2A) 1.4301
material double jacket
AISI304 (V2A) 1.4301
material legs
stainless steel
First Agitator
agitator
agitator flange
agitator positioning
eccentrically in the upper bottom
