Item no. K0316
46,000-liter vertical fruit juice tank made of stainless steel 304
€17,900.00 €21,301.00 incl. VAT
Price per piece, excl. VAT
1 on Stock
Select „share“ below, in order to generate an email template with the link to this corresponding product.
Share this product with someone
General Information
manufacturer
location
Satellite office
condition
used
Vessel
volume
46.000 liter
construction
standing
support type
legs height adjustable
quantity legs
5 pieces
Technical Characteristics
diameter outside
3.000 mm
cylindrical height
5.750 mm
total height
7.450 mm
Wall thickness lower bottom
5 mm
wall thickness cylinder
2.5 mm
wall thickness of upper bottom
4 mm
Equipment
manhole
in the cylinder (appr. 340 x 440 mm)
nameplate
technical equipment
ventilation, lifting lugs
outlet
flange DN100
remarks
Ventilation hood is missing
latest application
fruit juice
Material Composition
surface inside
weldings grinded
material in contact w/ medium
AISI 304 1.4301
Agitator
agitator
agitator flange
agitator positioning
laterally at the cylinder
