Item no. K0318
39,000-liter vertical pressure tank made of stainless steel 316
€24,500.00 €29,155.00 incl. VAT
Price per piece, excl. VAT
1 on Stock
Select „share“ below, in order to generate an email template with the link to this corresponding product.
Share this product with someone
General Information
manufacturer
AURICH Edelstahl GmbH
location
Satellite office
condition
used
Vessel
volume
39.000 liter
vacuum
0.3 bar
max. allowable working pressure
0,95 bar
max. allowable working temperature
95 °C
heads
torispherical bottom
construction
standing
support type
legs height adjustable
quantity legs
6 pieces
Technical Characteristics
diameter outside
3.000 mm
cylindrical height
4.850 mm
total height
6.600 mm
Wall thickness lower bottom
5.5 mm
wall thickness cylinder
5 mm
wall thickness of upper bottom
5 mm
Equipment
manhole
in the upper bottom (Ø 430)
nameplate
technical equipment
lifting lugs
outlet
pipe end Ø appr. 65mm
remarks
2 circumferential reinforcement/vacuum rings (80 mm wide); diameter including vacuum rings: approx. 3,160 mm
Material Composition
material in contact w/ medium
AISI 316Ti 1.4571
